LY-200 Wheel Water Well Drilling Rig
Featuring an upgraded gear-oil gearbox system, the LY-200 delivers better sealing, longer service life, and deeper drilling performance.
Why Buyers Choose The LY-200 Wheel Drilling Rig
Compared with crawler drilling machines, LY-200 provides easier towing, lower operating complexity and practical mobility for flat roads, farms and villages.
200m Drilling Capacity
- Suitable for common water well drilling
- Works for irrigation and residential boreholes
- Designed for 70-350mm hole diameter
Wheel-Mounted Mobility
- Easy to tow between job sites
- Suitable for farms, villages and field roads
- Lower transport complexity than crawler rigs
32HP Diesel Engine
- CHANGCHAI diesel engine configuration
- Independent power for rural job sites
- Practical for overseas users
Hydraulic Lifting System
- Stable feeding and lifting performance
- Easy machine operation
- Efficient drilling control
Compact Machine Body
- Suitable for smaller work sites
- Convenient for container shipment
- Easy maintenance and operation
Factory-Built Export Machine
- Real product photos with LIYO watermark
- Spare parts and drilling tools available
- Configuration support for overseas projects
LY-200 Technical Specification Matrix
Below are the standard specifications prepared for the LY-200 wheel water well drilling rig page. Final configuration can be adjusted according to geology and project requirements.
| Parameter Item | Standard Specification | Engineering Advantage |
|---|---|---|
| Model | LY-200 | Wheel hydraulic water well drilling rig |
| Maximum Drilling Depth | 200m | Suitable for common water wells and irrigation wells |
| Hole Diameter | 70-350mm | Flexible borehole range for different projects |
| Diesel Engine Brand | CHANGCHAI | Reliable diesel engine configuration |
| Engine Power | 32HP | Provides drilling power for borehole projects |
| Chassis Type | Wheel-Mounted Trailer Chassis | Easy movement on farms and flat roads |
| Drilling Method | Mud Rotary Drilling | Suitable for common soil and water well drilling |
| Mobility | Towed Movement | Can be moved by vehicle or tractor |
| Machine Weight | 650 kg | Compact and easy to transport between drilling sites |
| Machine Dimension | 1950 × 1000 × 1840 mm | Compact footprint for easy transport and storage |
Real Factory Photos Show Machine Structure
These photos show the actual LY-200 wheel drilling rig, including the trailer chassis, drilling mast, hydraulic system and compact machine structure.
Built For Farms, Villages And Small Borehole Projects
Trailer Chassis
The wheel-mounted structure allows the drilling rig to be towed between nearby job sites, reducing transport preparation for farms and rural projects.
Simple Operation
The compact hydraulic structure is designed for practical drilling contractors who need easy operation and maintenance.
32HP Diesel Power
The CHANGCHAI 32HP engine provides independent power for projects in remote areas without external electricity supply.
Where LY-200 Can Be Used
Agricultural Irrigation Wells
Suitable for irrigation water source development in farms, plantations and rural agricultural areas.
Water Well Drilling Projects
Used for residential water wells, village water supply and small-to-medium borehole projects.
Small Borehole Drilling
Can be used for basic borehole drilling, rural water supply and field drilling work.
Configuration Options For Global Buyers
Drill Pipe & Bit Selection
Drill rods, soil drill bits, tricone bits and other drilling tools can be selected according to local formations.
Logo & Color Customization
Machine color, logo mark and dealer branding can be customized for distributors and project customers.
Export Packing Support
Machines, drill rods, accessories and spare parts can be packed for overseas container transportation.
Real Manufacturing And Export Support
LIYO Machinery provides water well drilling rigs, wheel borehole drilling machines and hydraulic drilling equipment for global buyers. Learn more about our manufacturing capability on the About LIYO Machinery page.
LY-200 FAQ
Q1: What is the maximum drilling depth of the LY-200?
The recommended maximum drilling depth is 200 meters, depending on geology, hole diameter and drilling method.
Q2: What hole diameter can it drill?
The LY-200 supports 70-350mm hole diameter, suitable for water well drilling, farm irrigation and borehole projects.
Q3: What is the advantage of wheel chassis?
The wheel chassis is easier to tow and move on farms, villages and flat roads, making it suitable for small drilling contractors.
Q4: What engine configuration does it use?
The standard configuration uses a CHANGCHAI 32HP diesel engine for drilling work.
Q5: Can I customize drill rods and drilling tools?
Yes. Drill rods, drill bit types, spare parts and accessory packages can be customized according to project requirements.
Request A Quote
Tell us your drilling depth, hole diameter and project country. Our engineers will recommend the best configuration for you.
